SFD1200-12BG Front-End Preliminary Data Sheet
DC Input, 12V Output, 1200 Watts
Features
?
?
?
?
?
?
?
RoHS compliant for all six substances
Wide DC input range (-40 to -75 VDC)
1U or 2U height configurations
Active current share with ORing FET on +12V
I 2 C interface status and control
Standby voltage of 3.3 VDC @ 3 A
Overtemperature, overload, and overvoltage
protection
? Variable-speed fan for low noise at low ambient
temperatures
? Status LEDs: INPUT OK, OUTPUT OK, and
Applications
FAULT
? Datacom
? Distributed power systems
? Servers
Description
The SFD1200-12BG is a 1200-watt, DC-input front-end which has a main 12 VDC output for datacom, distributed
power, and server applications, and provides a 3.3 VDC standby output. Its compact size enables mounting in both
1U and 2U height racks. High efficiencies, advanced thermal management techniques, and an internal fan increase
reliability over a broad range of operating conditions. Internal ORing FETs facilitate use in hot-swap, redundant
configurations.
Status is provided with front panel LEDs, logic signals, and via an I 2 C management interface bus. In addition, the
I 2 C bus can supply status information about the power supply including output current and voltage.
The SFD1200-12G meets international safety requirements for ITE and is CE marked to the Low Voltage Directive
(LVD).
Model Selection
Nominal
Ripple &
Output
Maximum
Noise @
Voltage
Adjustment
Minimum Load
Output Current
Regulation
20 MHz
Model
SFD1200-12BG
(VDC)
12
3.35 (Standby)
Range (VDC)
N/A
N/A
(A)
0.5
0
(Amps)
99.2
3
%
± 3
± 3
BW (mV)
100
100
MCD10133 Rev. 1.1, 6-June-11
Page 1 of 8
www.power-one.com
